Round Zeppelin LED Spotlight

The Zeppelin Tondo LED Spotlight by Egoluce, designed by UT in 2008, is a walkable recessed spotlight, ideal for outdoor and indoor applications that require resistance and durability. With a round flange in AISI 316L stainless steel, an aluminum heatsink and a 30 cm neoprene cable, this spotlight is designed to withstand atmospheric agents and daily wear, ensuring long life and quality lighting.

Product Features:

• Type: Recessed lamps, outdoor lamps
• Materials:
  • Flange: AISI 316L stainless steel
  • Heatsink: Aluminum
  • Cable: 30cm Neoprene
• Designer: UT Egoluce
• Year of design: 2008
• IP rating: IP67 (protected against dust and temporary immersion in water)
• Net weight: 0.08 kg

Technical Specifications:

• Light source: Integrated Power LED
  • White light:
    • 2700K (Extra Warm White - XW) - 1.5W, 500mA, 199lm
    • 3000K (Warm White - WW) - 1.5W, 500mA, 210lm
    • 4000K (Neutral White - W) - 1.5W, 500mA, 221lm
  • Option on request: 5000K (Cool White)
• Color Rendering Index (CRI): CRI > 80

Installation:

• Plasterboard mounting: Using the supplied accessory
• Mounting on masonry: Requires specific formwork, to be ordered separately
• Power supply: Requires special driver to operate (order separately); dimmable drivers for PUSH, 1-10V, or DALI control are also available

Optional Accessories:

• Art. 0216: Plastic back case
• Art. 0220: Draining formwork kit + watertight connector, Draining junction box kit + IP connector

Advantages:

• Resistance and durability: Thanks to the AISI 316L stainless steel flange and the IP67 protection rating, the spotlight is resistant to atmospheric agents, ideal for outdoor applications and areas subject to pedestrian traffic.
• Efficient lighting: Available with different color temperatures and a high color rendering index, it guarantees quality lighting that enhances environments.
• Ease of installation: It can be mounted on plasterboard or masonry, with specific accessories for different installation needs.
• Control System Compatibility: Supports the use of dimmable drivers to customize light intensity and create different atmospheres.

Usage:

The Zeppelin Round LED Spotlight is ideal for outdoor and indoor applications that require reliable and durable lighting, such as gardens, driveways, entrances, terraces, or pedestrian areas. Thanks to its robustness, color temperature options and installation flexibility, it represents a versatile and durable solution for any architectural lighting project.
